    RWC5021P Tester for LoRa® / LoRaWAN​® is a compact dongle-type tester for LoRaWAN® protocol analysis for end devices, providing the pre-certification test function and link analyzer function that can be performed in signaling mode.
    The RWC5020x PC application software provides the LoRaWAN pre-certification test function to verify compatibility with the LoRaWAN protocol, which is fully available for all regions.



      LoRaWAN® Compliance


    Confirming that the end device meets the functional requirements of the LoRaWAN®​ protocol specification

    The LoRaWAN pre-certification test is fully available in the RWC5020x for all regions. Some of the pre-certification test items could be limited or not fully covered due to the limitation of maximum number of channels supported simultaneously.



    Supported Pre-certification Test Option

    LoRaWAN Specification 1.0.2:​

     - LoRa Alliance® European EU 863-870MHz Region End Device Certification Requirements document

     - LoRa Alliance® US + Canada US902-928MHz Region End Device Certification Requirements document

     - LoRa Alliance® Asia AS 923MHz Region End Device Certification Requirements document

     - LoRa Alliance® South Korea 920-923MHz Region End Device Certification Requirements document

     - LoRa Alliance® India 865-867MHz Region End Device Certification Requirements document



    LoRaWAN Specification 1.0.4:​

    - LoRaWAN 1.0.4 End Device Certification Requirements for All Regions

    - Supported Regions: EU863-870, US 902-928, AS923-1, AS923-2, AS923-3, AS923-4, KR920-923, IN865-867,

    AU915-928, RU864-870, and EU433



    Supported LoRaWAN®  Region

     EU 868 // EU 433 // US 915 // AU 915 // CN 470 // KR 920 // AS 923 // IN 865 // RU 864



    Supported LoRaWAN®  Protocol

     - Compatible with LoRaWAN® version of V1.0.2, V1.0.3, V1.0.4 and V1.1.0

     - Class A/B/C







      LoRa® /LoRaWAN® Test Solutions


    Protocol & Functional Test

     Support of LoRaWAN® Pre-Certification Tests for all regions

     - Scenarios for transmission of MAC commands and user application data

     - FUOTA Test with user firmware binaries



    PC Application Software

     - Fully Automated for Execution of All Built-in Functions

     - MAC and Application Protocol Messages Logging
